Gemini Ultra MIMO Sector Antenna

SkyWave

Questions? 0908-4655440

Gemini Ultra MIMO Sector Antenna Gemini Ultra MIMO Sector Antenna Gemini Ultra MIMO Sector Antenna Gemini Ultra MIMO Sector Antenna Gemini Ultra MIMO Sector Antenna Gemini Ultra MIMO Sector Antenna Gemini Ultra MIMO Sector Antenna Gemini Ultra MIMO Sector Antenna Gemini Ultra MIMO Sector Antenna
Quick Payment Options
Gemini Ultra MIMO Sector Antenna   P 4,850.00

Gemini Ultra MIMO Sector Antenna

Gemini Ultra MIMO Sector Antenna

High Gain MIMO

The SkyWave Gemini Ultra MIMO Sector Antenna is a high gain MIMO-ready antennas with a maximum range of 8 kilometers. It is suitable for city use and for other high-density areas.

Wide frequency range 1800 ~ 2600 Mhz supports multiple 5G and 4G LTE bands.

SkyWave Gemini MIMO Panel Antenna

5G Ready

Ready for the Next Generation

Worried that our antennas will not work with 5G? Worry no more. The SkyWave Gemini Ultra MIMO Sector Antenna is compatible with your sub-6Ghz 5G devices.

5G Ready

Dual Polarity Antenna

MIMO Ready

Take Advantage of your 5G and 4G LTE MIMO Connection

SkyWave Gemini Ultra MIMO Sector Antennas are 2x2 MIMO ready to take advantage of your network's maximum 5G and 4G LTE speeds.

2 cables from the antenna are ready to connect to your device's external antenna ports.

Base Station Class Antenna

The SkyWave Ultra Gemini MIMO Sector Antenna is a base station class antenna.

Enjoy the full benefits of base station class MIMO antenna for your 5G and 4G LTE in your home or office.

MIMO Ready

Conquer Distance

Conquer Distance

Conquer distance with the Skywave Gemini Ultra MIMO Sector Antennas.

SkyWave Gemini MIMO Sector Antennas have a maximum range of 8 kilometers (with clear line of sight). No more second guessing, no more worries on your internet connection.

World-Class Cables

All SkyWave Antennas are bundled with superior LMR240 cables made for data communications.

LMR240 cables are shielded, high quality, low-loss cables made for data communications.

Each LMR240 cable is terminated with heavy-duty N-type connector for better outdoor performance.

Heavy-Duty Connectors

Don't compromise for anything less.

World Class LMR240 Cables

Freebies

Frebies

Just like our facebook page to avail of 10 Cable Clips for cable management for FREE with your purchase of SkyWave Antennas.

Click on the photo to proceed to our facebook page (and like it!).

Made for the Outdoors

Tough and Weatherproof

Tough and weatherproof, all SkyWave Antennas are made for long-term outdoor use.

The Gemini MIMO Sector Antenna is a base station class antenna that has superior ABS Radome material for extra protection.

Compatible with Your Device

Compatible with your Device

All SkyWave Antennas are compatible with your modem device from Huawei, ZTE, and GreenPacket that has an external antenna port.

External antenna ports supported are: TS9, SMA, and RPSMA-Female.

Our cables are SMA-Male by default. TS9 and RPSMA-Male converters are available.

TS9 Connector
SMA Connector
RPSMA Connector
TS9 Connector SMA Connector RPSMA-Male Connector

Gallery

SkyWave Gemini MIMO Sector Antenna SkyWave Gemini MIMO Sector Antenna SkyWave Gemini MIMO Sector Antenna SkyWave Gemini Ultra MIMO Sector Antenna SkyWave Gemini Ultra MIMO Sector Antenna

Specifications

Gemini Ultra MIMO Sector Antenna
Model Number 2000GPD16x2
Antenna Type MIMO Sector (Dual Polarity)
Frequency Range 1790 ~ 2600 Mhz
Application 5G / 4G LTE / 3G
Gain 16 dbi
Horizontal Beamwidth 65°
Vertical Beamwidth 15°
VSWR < 1.5:1
Impedance 50 Ω
Front to Back Ratio 23
Max Power 50 watts
Polarization ±45° (MIMO)
Connector N-Female
Connector to Device SMA-Male
Dimension 500 x 120 mm
Weight 4 kg
Material Radome ABS
Directional True
Unit Price P 4,850.00

Options

Cable Upgrade Converter Delivery
LMR240 15 Meters: P275.00 SMA to TS9 Converter (Straight): P275.00 LBC Express: P655.00
LMR240 20 Meters: P550.00 SMA to TS9 Converter (Pigtail): P300.00 JRS Express: P450.00
LMR240 25 Meters: P875.00 SMA to RPSMA-Male Converter (Straight): P250.00
LMR240 30 Meters: P1,150.00 SMA to N-Male Converter (Straight): P300.00
LMR400 10 Meters (N-M/N-M): P850.00 N-Female to SMA-Male Converter (Pigtail): P400.00
LMR400 20 Meters (N-M/N-M): P2,150.00 N-Female to TS9 Converter (Pigtail): P400.00

* Prices stated above are per piece.

* SkyWave MIMO Antennas (Gemini, Gemini Ultra, MIMO Omnifiberglass, Zensei Ultra MIMO) require 2x LMR240 cables.
