Load-Balancing 5-Port VPN Router (ER518)

SkyWave

Questions? 0908-4655440

Load-Balancing 5-Port VPN Router (ER518) Load-Balancing 5-Port VPN Router (ER518)
Quick Payment Options
Load-Balancing 5-Port VPN Router (ER518)   P 3,250.00

Load-Balancing 5-Port VPN Router (ER518)

Load-Balancing 5-Port VPN Router (ER518)

The UTT ER518 Business VPN Router provides enterprise-level, highly secure, and reliable connectivity to the Internet for your business.

ER840G has 5 configurable 10/100 ports for WAN or LAN which will offer multiple choices for ISP connections and real-time backup, failover, and load balance. Ports can be configured to at most 4x WAN ports + 1x LAN port, or 4x LAN ports + 1x WAN port.

Give your business the technology edge over the competition!

Load-Balancing Router

The ER518 supports load-balancing function for multiple WAN connections. This means the device will distribute the connection according to different IP address or NAT session.

Furthermore, it also supports policy-based routing of different ISPs.

Load-Balancing

Backup and Failover

Failover and Backup

The ER8518 also supports real-time backup and failover. When two or more Internet connections are set up, one can set as the primary connection and the other one as the backup connection.

Policy-Based Routing

The ER518 supports policy-based routing of internet traffic. Users can implement unique access policies for different devices/accounts.

ER840G supports domain name filtering. Users can either block websites or only allow websites.

ER840G supports IP/MAC address binding, invalid IP address, MAC address filtering and easy blacklist/whitelist setting.

ER840G supports binding all the dynamic IP/MAC entries with only one-click operation.

Policy-Based Routing

Secure Connection via VPN

VPN

Unlike other load-balancing routers, the ER840G supports up to 5 IPSec/PPTP VPN tunnels.

Users can setup site-to-site or client-to-site virtual private network (VPN) via dynamic IP address or domain names.

Flexible Bandwidth Control

Flexible bandwidth will guarantee the webpage browse and essential network applications.

  • Adjust the bandwidth for users and applications flexibly, improve the real-time network performance, and recognize different application accurately.
  • Supports priority queues to ensure smooth transmission of applications which require large bandwidth.
  • Improved network performance will solve network congestion and unreasonable bandwidth allocation.
  • Reasonable network traffic distribution, optimized bandwidth utilization, stable, fast, safe and efficient network environment.

This very unique feature can optimize bandwidth for maximum network performance with only two steps: 1) enable this function, and 2) set up a specific bandwidth for each Internet connection.

Failover and Backup

Business-Class Router

Business-Class Router

Industrial-class build offers worry-free high-availability for continuous operations.

Specifications

Load-Balancing 5-Port VPN Router (ER518)
LAN

3x 10/100 Mbps RJ45 ports (Auto-negotiation, auto MDI/MDIX)

WAN

2x 10/100 Mbps RJ45 ports (Auto-negotiation, auto MDI/MDIX)

Port Configuration

At most 4x WAN ports + 1x LAN port or 4x LAN ports + 1x WAN port

File Sharing Yes
Internet Connection Static IP, DHCP and PPPoE
Network Address Translation (NAT)

Port Address Translation(PAT), Network Address Port Translation (NAPT), UPnP

Routing Protocol Static
DMZ Yes
DDNS Support No-IP, DynDNS
DHCP Server Yes
PPPoE Server Yes
VPN Max Tunnels

Concurrent: 5

Configured: 5

IPSec VPN Gateway-to-gateway IPSec tunnels
PPTP VPN

Gateway-to-gateway PPTP tunnels

Client-to-gateway PPTP tunnels

Firewall

ARP spoofing

Port scanning

DDoS/DoS attack

UDP, ICMP, SYN Flood attack

Access Control

MAC address filter

Whitelist

Blacklist

One-click filtering of address

Packet Filtering Packet filtering based on: IP address, protocol, port
Content Filtering Filtering on URL, key words and DNS on application layer
Web Authentication Yes
IP/MAC Binding Yes
Rate Limiting

Fixed rate limiting

Flexible bandwidth control

Session Limiting Limitation on maximum NAT sessions
Management Interface HTTP (Web GUI)
Language English
Event Logging Local
Event Notification Yes
Internet-based Audit Yes
Firmware Upgrade Yes, upgradable through web browser with imported/exported configuration file
System Time Supports SNTP, Day Light Savings, Manual entry
Dimensions 7.9 x 4.9 x 1.1 in.(200 x 125 x 28mm)
Weight 2.14lb or 0.97kg
Installation LAN Cable (Wired)
Buttons Reset
LED Power, SYS, USB, Link/Act
Power DC 12V 1A
Power Consumption 6W
Operating Temperature 0 to 40C (32 to 104F)
Operating Altitude 0 to 4000m
Operating Humidity 10% to 90% (noncondensing)
Color Black
Unit Price P 3,250.00
